Measurement
- Refractometer Sphere: -25.00D ∼ +25.00D
- Cylinder: 0D ∼ ±10.00D
- Axis: 1º to 180°
- Keratometer Radius curvature: 5.00mm ∼ 10.00mm
- Refractive power: 67.50D to 33.75D
- Astigmatism: 0D ∼ ±10D
- Astigmatic axis: 1º ∼ 180º
- Peripheral measurement: 6.0mm
Specifications
- Display: Tilt-able wide 7 inch TFT LCD
- Printer: Built in thermal printer with cutting
- Interface: RS-232, RGB (Video out)
- Dimension: 270mm x 520mm x 455mm
- Weight: approx. 18kg Power Supply: 100 – 240 VAC 50/60 Hz
