Specification
  • Angle of convargence: 13º
  • Magnification; 10x and 16x
  • Working distance; approx. 80mm (at 16x magnification) and approx. 100mm (at 10x magnification)
  • Practical field of view; 10mm (at 16x magnification) and 15mm (at 10x magnification)
  • Interpupillary adjusment range; 50 to 72 mm
  • Diopter adjustment range; -8D to +5D
  • Slit width; 0.1mm , 0.2mm, 0.8mm
  • Spot size; 1mm, 5mm, 12mm and shape ellipse
  • Light intensity adjusment: continous variable
  • Slit illuminating angle: Horizontal, 60º
  • Filter: built-in blue filter
  • Light source: White LED
Accessories
  • Dust cover
  • Video camera
  • Carrying case


Portable SlitLamp SL-17
Kowa Portable Slit Lamps are Now LEDs!
  • 20,000 lux white LED light source, Illumination is thumb wheel controlled and illuminated for easy viewing in a darkened room.
  • Powered by AAA batteries, Kowa SL-17 use the following commercially available batteries: AAA rechargeable batteries AAA dry cell batteries (Excludes lithium-ion and lithium batteries).
  • Anti-tip design, New circular base increases slit lamp stability providing a safer place to store the instrument.
  • Digital image support, Optional camera adapter with diffusion cylinder and yellow filter is available which allows documentation of anterior segment through image and video capture.
